3/4 " pitch 제이콥 체인 스프라켓, 60-1열   sprocket60-1.xls 다운받기

주문예 : 제이콥 스프라켓 60-BTB-11H, 1008 x 19 mm 표준키홈



열처리 타입-H
No.
Teeth		 Catalog
Number
11
12
13		 60BTB11H
60BTB12H
60BTB13H
14
15
16		 60BTB14H
60BTB15H
60BTB16H
17
18
19		 60BTB17H
60BTB18H
60BTB19H
20
21
22		 60BTB20H
60BTB21H
60BTB22H
23
24
25		 60BTB23H
60BTB24H
60BTB25H
26
27
28
30		 60BTB26H
60BTB27H
60BTB28H
60BTB30H


Single-Taper Bushed

NO.
Teeth		 Catalog
Number		 Bushing Diameter Max.
Bore		 Dimensions Type Weight(Approx.)
Outside
Diameter		 Pitch
Diameter		 L C Rim
Only		 Bushing
Only
11
12
13
14
15		 60BTB11
60BTB12
60BTB13
60BTB14
60BTB15		 1008
1008
1210
1210
1610		 3.004
3.249
3.493
3.736
3.979		 2.662
2.898
3.134
3.371
3.607		 1
1
1 1/4
1 1/4
1 5/8		 7/8
7/8
1
1
1		 1 13/16
1 15/16
2 15/32
2 15/32
2 15/32		 B,D
B,D
B,D
B,D
B,D		 .6
.8
.8
1.0
1.0		 .3
.3
.6
.6
.9
16
17
18
19
20		 60BTB16
60BTB17
60BTB18
60BTB19
60BTB20		 1610
1610
1610
1610
2012		 4.221
4.462
4.704
4.945
5.185		 3.844
4.082
4.319
4.557
4.794		 1 5/8
1 5/8
1 5/8
1 5/8
2		 1
1
1
1
1 1/4		 3
3 1/4
3 1/4
3 1/4
3 9/16		 B,D
B,D
B,D
B,D
B,D		 1.4
1.8
1.9
2.2
2.2		 .9
.9
.9
.9
1.7
21
22
23
24
25		 60BTB21
60BTB22
60BTB23
60BTB24
60BTB25		 2012
2012
2012
2012
2012		 5.426
5.666
5.907
6.147
6.387		 5.032
5.270
5.508
5.746
5.984		 2
2
2
2
2		 1 1/4
1 1/4
1 1/4
1 1/4
1 1/4		 3 9/16
3 9/16
3 9/16
3 9/16
3 9/16		 B,D
B,D
B,D
B,D
B,D		 2.5
2.8
3.1
3.4
3.7		 1.7
1.7
1.7
1.7
1.7
26
27
28
30
32		 60BTB26
60BTB27
60BTB28
60BTB30
60BTB32		 2012
2012
2012
2012
2012		 6.627
6.867
7.107
7.586
8.065		 6.222
6.416
6.699
7.175
7.652		 2
2
2
2
2		 1 1/4
1 1/4
1 1/4
1 1/4
1 1/4		 3 9/16
3 9/16
3 9/16
3 9/16
3 9/16		 B,D
B,D
B,D
B,D
B,D		 4.0
4.2
4.6
5.2
5.6		 1.7
1.7
1.7
1.7
1.7
35
36
40
42
45		 60BTB35
60BTB36
60BTB40
60BTB42
60BTB45		 2012
2012
2012
2012
2012		 8.783
9.022
9.980
10.458
11.175		 8.367
8.605
9.559
10.036
10.752		 2
2
2
2
2		 1 1/4
1 1/4
1 1/4
1 1/4
1 1/4		 3 9/16
3 9/16
3 9/16
3 9/16
3 9/16		 B,D
B,D
B,D
B,D
B,D		 6.4
6.6
8.3
10.0
11.5		 1.7
1.7
1.7
1.7
1.7
48
54
60
70
72		 60BTB48
60BTB54
60BTB60
60BTB70
60BTB72		 2012
2517
2517
2517
2517		 11.893
13.327
14.761
17.150
17.628		 11.467
12.899
14.330
16.717
17.194		 2
2 1/2
2 1/2
2 1/2
2 1/2		 1 1/4
1 3/4
1 3/4
1 3/4
1 3/4		 3 9/16
4 1/4
4 1/4
4 1/4
4 1/4		 B,D
B,D
B,D
B,D
B,D		 13.2
17.1
21.0
27.6
30.0		 1.7
3.5
3.5
3.5
3.5
80
84		 60BTB80
60BTB84		 2517
2517		 19.539
20.494		 19.103
20.058		 2 1/2
2 1/2		 1 3/4
1 3/4		 4 1/4
4 1/4		 B,D
B,D		 36.3
40.6		 3.5
3.5
＊Has recessed groove in hub for chain clearance.
