| Size |
허용토오크(kg.m) |
허용
최대
Radial
Load |
Max.
Speed
(rpm) |
Bore Dia
(mm) |
Dimensions(mm) |
Cpig
Wt(kg) |
GD2
1kg(m2) |
볼트
체결
토오크
(kg.m) |
Radial
Load |
1/3
Load |
2/3
Load |
Max.
Radial
Load |
Emax |
A |
B |
F |
G |
H |
J |
| 05S |
3.4 |
1.5 |
1.2 |
0.8 |
15 |
47,000 |
23 |
67 |
55.8 |
25 |
5.8 |
33 |
16 |
0.6 |
8 |
0.9 |
| 10S |
9.2 |
4.1 |
3.2 |
2.3 |
25 |
39,000 |
32 |
81 |
57.1 |
25 |
7.1 |
46 |
16 |
1.1 |
24 |
0.9 |
| 15S |
18 |
8.1 |
6.3 |
4.5 |
56 |
34,000 |
35 |
93 |
66.4 |
29 |
8.4 |
51 |
24 |
1.7 |
48 |
2.2 |
| 20S |
25 |
11.3 |
8.7 |
6.0 |
83 |
30,000 |
42 |
104 |
79 |
34 |
11 |
61 |
30 |
2.5 |
80 |
2.2 |
| 25S |
43 |
19.3 |
16.0 |
11.0 |
120 |
25,000 |
50 |
125 |
93.2 |
41 |
11.2 |
71 |
27 |
4.3 |
224 |
4.2 |
| 30S |
79 |
35.5 |
27.6 |
20.0 |
180 |
22,000 |
58 |
143 |
108.5 |
48 |
12.5 |
84 |
28 |
6.9 |
440 |
7.3 |
| 35S |
130 |
58.5 |
45.5 |
32.5 |
270 |
19,000 |
74 |
168 |
130 |
57 |
16 |
106 |
26 |
11.3 |
1080 |
7.3 |
| 40S |
210 |
94.5 |
73.4 |
52.5 |
380 |
16,000 |
83 |
194 |
145 |
64 |
17 |
118 |
30 |
16.7 |
2080 |
15.9 |
| 45S |
340 |
153 |
19 |
85 |
450 |
15,000 |
95 |
214 |
174.8 |
76 |
22.8 |
137 |
34 |
22.7 |
3520 |
15.9 |
| 50S |
500 |
225 |
171 |
125 |
610 |
13,000 |
109 |
246 |
202 |
89 |
24 |
156 |
26 |
35.4 |
7200 |
22.1 |
| 55S |
650 |
292 |
227 |
163 |
770 |
11,000 |
118 |
276 |
230 |
102 |
26 |
169 |
42 |
52.0 |
12800 |
55.3 |
|
